ZP200 Ultra-thin smart passport machine
Describe：This product is an efficient and convenient smart passport card reader device, relying on OCR (Optical Character Recognition Technology) technology, which can quickly identify the MRZ (Machine Readable Zone) information of the extracted passport, so as to accurately read the electronic chip information in the passport.
Product features
² High-precision recognition: Advanced OCR technology is adopted, and the recognition accuracy is high
² Easy to operate: plug and recognize, no complicated operation
² Small and portable: Compact in size, easy to carry, can be used anytime, anywhere.
² Multi-platform use: support Windows and Android platforms
² Easy development: standard USB interface, source code SDK provided
Product technical parameters
Classify | Parametric indicators | Parameter description |
Electrical parameters | Communication interfaces | USB |
Operating voltage | 5V | |
Operating current | 300ma | |
Methods of Communication | USB2.0 | |
size | 138x72x22(mm) | |
OCR(MRZ)identify | Image size | 118x2(mm) |
Identify the number of MRZ rows | 1.line:IDL,CAN，... | |
2.line:ID2 cards,ePP | ||
3.line:eID | ||
Acquisition speed | <1.3s | |
Card reader | Communication protocols | CCID,PC/SC |
Communication rate | 600kbpsIt supports up to 600kbps | |
Automatically triggered | It supports automatic sensing of documents to trigger document reading | |
Contactless cards | ISO 14443 Type A and B ICAO9303 standard passport | |
Mifare Classic 、 Mifare Ultralight C | ||
Card clock frequency：13.56MHz | ||
Card read and write speed：106kbps | ||
Card reading speed | 1-2s | |
Working environment | Operating temperature | -20°C ~ 60°C |
humidity | 0% ~ 90% RH（Non-condensing） | |
Electrostatic rating | Contact 8kV/Non-contact 15kV | |
Light | Power lights | The power is turned on and the red light is on |
Status lights | The green light flashes at work | |
Warning lights | Unusual yellow light flashing | |
Systems | operating system | Windows android |
Pictures and dimensions
